Durable SS 304 Primary Colour Stainless Steel Woven Wire Mesh
Stainless Steel Woven Wire Mesh Technology
Plain weave, twill weave, mat weave, resistance welding, etc.
1. Plain stainless steel mesh:
The most common weaving method is widely used in industrial
production and civil life. The main feature is that the density of
warp and weft diameter is the same.
2. Stainless steel square mesh
Material: galvanized iron wire, stainless steel wire, copper wire,
aluminum wire, etc. Features: precise structure, uniform mesh, good
corrosion resistance, strong and durable. Widely used in industry
and construction industry, screening sand, filtering liquid and
gas. It can also be used for the safety protection of mechanical
accessories, and it can also be used to make walls and ceilings
instead of wooden strips.
3. Stainless steel mat / dense mesh
Material: stainless steel wire, low carbon steel wire, nickel wire,
copper wire, polyester wire, etc. Weaving: plain weave, twill
weave, bamboo flower weave, contrast weave. Features: good
filtering precision, high load intensity of contrast net.
Application: used in aerospace, petroleum, chemical industry,
scientific research and transportation industry, also can make
lunch box net, coal washing net, etc.
Stainless Steel Woven Wire Mesh Usage
1. It is used for screening and filtration in acid and alkali
environment. In petroleum industry, it is used for mud screen,
chemical fiber industry, screen screen and electroplating.
2. Used in mining, petroleum, chemical, food, medicine, machinery
manufacturing and other industries.
3. It is used for screening and filtering in acid and alkali
environment. It is used for mud screen in petroleum industry,
chemical fiber screen and acid washing screen in electroplating
industry.
Stainless Steel Woven Wire Mesh Technical Parameters:
| Square mesh, Plain weave or Twill weave |
| Aperture(mm) | Wire diameter(mm) | Mesh per inch(1inch=25.4mm) | Open area(%) | weight |
| W | D | MESH | FO | KG/M2 |
| 10.00 | 2.00 | 2.0 | 68 | 4.23 |
| 10.00 | 1.60 | 2.2 | 75 | 2.80 |
| 8.00 | 1.60 | 2.5 | 69 | 3.39 |
| 7.00 | 1.40 | 3.0 | 69 | 2.90 |
| 6.30 | 1.00 | 3.5 | 74 | 1.74 |
| 5.00 | 1.00 | 4.25 | 68 | 2.12 |
| 4.00 | 1.00 | 5.0 | 62 | 2.54 |
| 3.00 | 1.20 | 6.0 | 50 | 4.40 |
| 2.50 | 1.00 | 7.25 | 51 | 3.65 |
| 2.00 | 1.00 | 8.5 | 41 | 4.10 |
| 2.00 | 0.50 | 10.0 | 64 | 1.25 |
| 1.64 | 0.90 | 10.0 | 42 | 4.00 |
| 1.60 | 0.50 | 12.0 | 58 | 1.51 |
| 1.06 | 1.00 | 10.0 | 38 | 4.88 |
| 1.25 | 0.40 | 16.0 | 57 | 1.23 |
| 1.25 | 0.80 | 12.0 | 37 | 3.92 |
| 1.00 | 0.30 | 20.0 | 57 | 0.99 |
| 1.00 | 0.40 | 18.0 | 51 | 1.45 |
| 1.00 | 0.50 | 17.0 | 44 | 2.12 |
| 0.87 | 0.40 | 20 | 48 | 1.56 |
| 0.80 | 0.50 | 20 | 38 | 2.44 |
| 0.70 | 0.36 | 24 | 44 | 1.54 |
| 0.63 | 0.40 | 25 | 37 | 1.97 |
| 0.50 | 0.30 | 30 | 37 | 1.59 |
| 0.40 | 0.25 | 40 | 38 | 1.22 |
| 0.315 | 0.20 | 50 | 37 | 0.99 |
| 0.25 | 0.16 | 60 | 37 | 0.79 |
| 0.20 | 0.125 | 80 | 38 | 0.61 |
| 0.16 | 0.10 | 100 | 38 | 0.49 |
| 0.125 | 0.080 | 120 | 37 | 0.40 |
| 0.10 | 0.063 | 150 | 38 | 0.31 |
| 0.075 | 0.053 | 200 | 36 | 0.26 |
| 0.063 | 0.04 | 250 | 37 | 0.20 |
| 0.042 | 0.036 | 325 | 29 | 0.22 |
| 0.036 | 0.028 | 400 | 32 | 0.16 |
| 0.025 | 0.025 | 500 | 25 | 0.16 |
Stainless Steel Woven Wire Mesh Characteristics
Customized according to customer requirements:
Material: 201, 304, 304L, 316, 316L and other stainless steel wire
etc.
