Diversified Plain Twilled Dutch Weave Wire Mesh Stainless Steel

Ask Lasest Price
Brand Name :	LONGKUO METAL WIRE MESH
Price :	$6 ~ 99/roll
Payment Terms :	T/T, Western Union
Supply Ability :	100,000m2/year
Delivery Time :	About 7 work days depends on the supply

Add to Cart

Product Details
Company Profile

Diversified Plain Twilled Dutch Weave Wire Mesh Stainless Steel

Diversified Uses Plain Twill Dutch weave Customizable Stainless Steel Mesh

Stainless Steel Mesh Service

Our company has a large number of regular specifications of stock, according to customer requirements for production and processing and customization.

Stainless Steel Mesh Surface treatment:

Electropolishing, ring resin, electrostatic spraying, metal plating, ultrasonic, etc.

Stainless Steel Mesh Stainless steel standard steel grade comparison table and density table

China	Japan	USA	South Korea	EU	Australia	Taiwan, China	density t/m3
GB/T20878	JIS	ASTM	KS	BSEN	AS	CNS
12Cr13	SUS403	403	STS403	—	403	403	7.75
20Cr13	SUS420J1	420	STS420J1	1.4021	420	420J1	7.75
30Cr13	SUS420J2	—	STS420J2	1.4028	420J2	420J2	7.75
10Cr17	SUS430	430	STS430	1.4016	430	430	7.70
68Cr17	SUS440A	440A	STS440A	—	440A	440A	7.70
06Cr19Ni10	SUS304	304	STS304	1.4301	304	304	7.93
022Cr19Ni10	SUS304L	304L	STS304L	1.4306	304L	304L	7.93
06Cr17Ni12Mo2	SUS316	316	STS316	1.4401	316	316	7.98
022Cr17Ni12Mo2	SUS316L	316L	STS316L	1.4404	316L	316L	7.98
06Cr18Ni11Ti	SUS321	321	STS321	1.4541	321	321	7.93
06Cr18Ni11Nb	SUS347	347	STS347	1.455	347	347	7.98

Stainless Steel Mesh Technical Parameters:

Square mesh, Plain weave or Twill weave
Aperture(mm)	Wire diameter(mm)	Mesh per inch(1inch=25.4mm)	Open area(%)	weight
W	D	MESH	FO	KG/M2
10.00	2.00	2.0	68	4.23
10.00	1.60	2.2	75	2.80
8.00	1.60	2.5	69	3.39
7.00	1.40	3.0	69	2.90
6.30	1.00	3.5	74	1.74
5.00	1.00	4.25	68	2.12
4.00	1.00	5.0	62	2.54
3.00	1.20	6.0	50	4.40
2.50	1.00	7.25	51	3.65
2.00	1.00	8.5	41	4.10
2.00	0.50	10.0	64	1.25
1.64	0.90	10.0	42	4.00
1.60	0.50	12.0	58	1.51
1.06	1.00	10.0	38	4.88
1.25	0.40	16.0	57	1.23
1.25	0.80	12.0	37	3.92
1.00	0.30	20.0	57	0.99
1.00	0.40	18.0	51	1.45
1.00	0.50	17.0	44	2.12
0.87	0.40	20	48	1.56
0.80	0.50	20	38	2.44
0.70	0.36	24	44	1.54
0.63	0.40	25	37	1.97
0.50	0.30	30	37	1.59
0.40	0.25	40	38	1.22
0.315	0.20	50	37	0.99
0.25	0.16	60	37	0.79
0.20	0.125	80	38	0.61
0.16	0.10	100	38	0.49
0.125	0.080	120	37	0.40
0.10	0.063	150	38	0.31
0.075	0.053	200	36	0.26
0.063	0.04	250	37	0.20
0.042	0.036	325	29	0.22
0.036	0.028	400	32	0.16
0.025	0.025	500	25	0.16

Stainless Steel Mesh Company Introduction

Our factory is a chemical factory integrating production, sales, wholesale and retail. All products are provided with one-stop service. From wire drawing, mesh weaving, deep processing and inspection, we operate independently. All materials, sizes and specifications can be customized according to customer requirements. It is one of the largest manufacturers of stainless steel wire mesh in China. We have a large stock of many popular standard items.
