Customized Mesh 10 - 14 Wire Diameter Range 0.5mm - 1mm Stainless
Steel Diamond Mesh
Stainless Steel Diamond Mesh Specifications
11 mesh * 0.8mm, 12 mesh * 0.7mm, 14 mesh * 0.6mm, 14 mesh 0.55mm,
14 mesh 0.5mm. Mesh size: 1500mm * 3000mm; 1300mm * 2600mm; 1200mm
* 2000mm; 1200mm * 2400mm; 1000 * 2400mm; 900mm * 2000mm; 900mm *
2400mm; 750mm * 2000mm; 750mm * 2400mm.
Stainless Steel Diamond Mesh Technology
1. Raw materials for stainless steel wire drawing
2. Stainless steel drawing line production
3. Water tank wire drawing machine -- wire drawing and annealing
4. Stainless steel wire 0.50mm-1mm
5. Stainless steel mesh weaving
6. Stainless Steel Diamond mesh
7. Net washing
8. Net cutting
9. Plastic spraying
10. Packing and delivery
Stainless Steel Diamond Mesh Parameter table
| MESH | WIRE DIAMETER(mm) |
| 10 | 1mm / 0.9mm |
| 11 | 0.9mm / 0.8mm |
| 12 | 0.8mm / 0.7mm |
| 13 | 0.6mm |
| 14 | 0.50mm / 0.55mm / 0.60mm |
Stainless Steel Diamond Mesh Selling points
High impact resistance, anti-theft, bullet proof, mosquito proof,
high temperature resistance, flame retardant, high strength, strong
toughness, bright and beautiful surface color, can better increase
the air circulation rate and sunlight exposure. The anti-theft and
anti insect net is made of stainless steel wire. The surface is
sprayed with plastic, and the colors are (black, silver gray,
etc.). They are concealed on the aluminum doors and windows to make
them organically compound into one. The stainless steel net is
hidden in the window frame, and the aluminum strip is sealed, which
is beautiful and generous. It truly embodies the trinity of
anti-theft, insect prevention, ventilation and ventilation. And
emergency escape is convenient, no barrier, no shelter. Easy to
clean, as long as a cloth can clean very clean. Long service life,
up to 15-50 years.
Stainless Steel Diamond Mesh Technical Parameters
AISI
Material | Chemical omposition(%) |
| C | Si | Mn | P | S | Ni | Cr | Mo | Cu | Ti |
| 201 | ≤0.15 | ≤0.75 | 5.5~7.5 | ≤0.06 | ≤0.03 | 3.5~5.5 | 16~18 | - | - | |
| 304 | <0.08 | <1.0 | <2.0 | <0.035 | <0.03 | 8~10 | 17~19 | - | - | - |
| 304L | <0.03 | <1.0 | <2.0 | <0.04 | <0.03 | 9~13 | 18~20 | - | - | - |
| 316 | <0.08 | <1.0 | <2.0 | <0.04 | <0.03 | 10~14 | 16~18 | 2.0~3.0 | - | - |
| 316L | <0.03 | <1.0 | <2.0 | <0.04 | <0.03 | 12~15 | 16~18 | 2.0~3.0 | - | |
