In Coil Steel grade Stainless Steel 316L Diameter Range 1mm -
1.42mm Stainless Steel Light Cable
Product Information
Stainless steel wire, also known as stainless steel wire, is made
of stainless steel as raw material for various kinds of silk
products of different specifications and models. The cross section
is generally round or flat. The common stainless steel wires with
good corrosion resistance and high cost performance are 201, 304
and 316 stainless steel wires.
Technology
Stainless steel wire drawing is a metal plastic processing process
in which the wire rod or wire blank is pulled out from the die hole
of drawing die under the action of drawing force to produce small
section steel wire or non-ferrous wire. Wire with different cross
section shape and size of various metals and alloys can be produced
by drawing. The drawn wire has the advantages of accurate size,
smooth surface, simple drawing equipment and die, and easy
manufacturing.
Material composition table
AISI Material | Chemical composition (%) |
| C | Si | Mn | P | S | Ni | Cr | Mo | Cu | Ti |
| 201 | ≤0.15 | ≤0.75 | 5.5~7.5 | ≤0.06 | ≤0.03 | 3.5~5.5 | 16~18 | - | - | - |
| 304 | <0.08 | <1.0 | <2.0 | <0.035 | <0.03 | 8~10 | 17~19 | - | - | - |
| 304L | <0.03 | <1.0 | <2.0 | <0.04 | <0.03 | 9~13 | 18~20 | - | - | - |
| 304HC | <0.06 | <1.0 | 1.2-1.8 | <0.035 | <0.03 | 8~11 | 17~19 | - | 2.0-3.0 | - |
| 316 | <0.08 | <1.0 | <2.0 | <0.04 | <0.03 | 10~14 | 16~18 | 2.0~3.0 | - | - |
| 316L | <0.03 | <1.0 | <2.0 | <0.04 | <0.03 | 12~15 | 16~18 | 2.0~3.0 | - | - |
| 310S | <0.08 | <1.5 | <2.0 | <0.04 | <0.03 | 19~22 | 24~26 | - | - | - |
| 321 | <0.08 | <1.0 | <2.0 | <0.045 | <0.03 | 9~13 | 17~19 | - | - | >0.035 |
| 301 | <0.15 | <1.0 | <2.0 | <0.04 | <0.03 | >7 | 16~18 | - | - | - |
| 302 | <0.15 | <1.0 | <2.0 | <0.04 | <0.03 | >8 | 17~19 | - | - | - |
| | | | | | | | | | |
Specifications
1. Stainless steel soft wire, code: s, soft. Commonly known as
hydrogen wire: bright surface, soft, no magnetism, fatigue
resistance, large extension force and other characteristics.
Specification: 0.03-5.0mm, material: 201, 304, 304L, 316, 316L,
310, 310S, 321, etc.
2. Stainless steel light cable, code: LD, light draw. After heat
treatment, the steel wire shall be pulled with small reduction
surface. The surface is bright, soft, fatigue resistant, and has
certain elongation. Specification: 0.03-5.0mm, material: 201, 304,
304L, 316, 316L, etc.
3. Stainless steel cold cable, code: WCD, cold draw. The surface is
smooth, toughness is good and wear resistant. Specification:
0.03-6.0mm, material: 201, 304, 304L, 316, 316L, etc.
4. Stainless steel spring wire: high hardness, strong elasticity,
good wear resistance and compression resistance. Specification:
0.15-5.0mm, material: 302, 304H, 304L, 316, 316L, 310, 310S, 321,
etc.
