Electrostatic Powder Spraying Yellow Fence Razor Barbed Wire
Basis Information
Blade barbed rope, also known as blade barbed wire and blade barbed
net, is a new type of protective net. Blade thorn rope has the
advantages of beautiful, economical and practical, good resistance
effect, convenient construction and so on. Blade thorn rope is
widely used in many countries' industrial and mining enterprises,
garden apartments, border guard posts, military fields, prisons,
detention centers, government buildings and other countries'
security facilities.
Specifications
| Another name | Blade thorn rope, Blade gill, Prison fence gill net
|
| Main materials | Galvanized plate, stainless steel plate, high quality low carbon
steel wire
|
| Surface processing method | Galvanized, Electrostatic powder spraying
|
| Type | Spiral type, straight type, spiral cross type
|
| Classification | (snake belly type) Spiral blade gill net, single coil blade gill
net (single screw), linear blade gill net, flat blade gill net,
blade thorn rope welding net, single coil blade gill net (single
screw), etc
|
| Spray color | Blue, grass green, ink green, yellow, etc
|
| Packaging | Moisture proof paper, woven bag, other packaging can be in
accordance with customer requirements.
|
Product specification parameter table 1
| Specifications | Shape | Razor blade thickness | Centerline Diameter | Razor blade length | Razor Blade width | Razor Blade spacing |
| BTO-10 | | 0.5±0.05 | 2.5±0.1 | 10±1 | 13±1 | 25±1 |
| BTO-12 | | 0.5±0.05 | 2.5±0.1 | 12±1 | 15±1 | 25±1 |
| BTO-18 | | 0.5±0.05 | 2.5±0.1 | 18±1 | 15±1 | 35±1 |
| BTO-22 | BTO-22 | 0.5±0.05 | 2.5±0.1 | 22±1 | 15±1 | 36±1 |
| BTO-28 | BTO-28 | | | | | 46±1 |
| CBT-65 | | 0.5±0.05 | 2.5±0.1 | 65±2 | 21±1 | 100±2 |
Product specification parameter table 2
| Razor blade size |
Outside diameter | Number of turns | Standard cover length | Production form | Remarks |
| 450mm | 33 | 8M | CBT-65 | Single coil |
| 500mm | 41 | 10M | CBT-65 | Single coil |
| 700mm | 41 | 10M | CBT-65 | Single coil |
| 960mm | 53 | 13M | CBT-65 | Single coil |
| 500mm | 102 | 16M | BTO-10.15.22 | Cross type |
| 600mm | 86 | 14M | BTO-10.15.22 | Cross type |
| 700mm | 72 | 12M | BTO-10.15.22 | Cross type |
| 800mm | 64 | 10M | BTO-10.15.22 | Cross type |
| 960mm | 52 | 9M | BTO-10.15.22 | Cross type |
Characteristics
1. Protection ability: blade gill net is a sharp blade shaped
protective net made of stainless steel sheet and hot-dip galvanized
steel sheet. Because there are spikes on the blade thorn rope that
people can't touch, it can have better protection effect after use.
Moreover, the blade thorn rope itself has no point of force and
can't touch it for climbing. Therefore, it's very difficult to
climb over the blade thorn rope. The spikes on the blade thorn rope
can easily scratch the climber, or hook the climber's clothes, so
as to take care of people So, the protection ability of blade stab
rope is very good.
2. Beautiful appearance: the blade thorn rope has a spiral cross
style, which is more beautiful than the single style of galvanized
thorn rope. It is suitable for some better apartments for
protection, and will not produce a sense of being imprisoned in the
interior.
3. the product has excellent characteristics such as good
deterrence effect, convenient construction, economic and practical.
