Stainless Steel 304L Wire Diameter 0.15mm-6.0mm Mesh 3/4" x 3/4"
Welding Dutch network
Basis Information
Welded wire mesh is made of high-quality low-carbon steel wire, and
then cold plating (electroplating), hot plating, PVC plastic
coating and other surface passivation, plasticization treatment.
The results show that the mesh surface is smooth, mesh is uniform,
solder joint is firm, local machining performance is good, stable,
weather resistance and corrosion resistance are good.
Stainless steel welded wire mesh is made of high-quality stainless
steel wire. It is more acid resistant, alkali resistant, firmly
welded, beautiful and widely used.
Main product
Product 1: Plastic coated welded wire mesh
PVC coated welded wire mesh is a kind of high-profile welded wire
mesh. The upper part has protective barbed wire mesh. The wire mesh
is galvanized steel wire, and PVC coated plastic treatment is added
to ensure the maximum firmness and durability while protecting the
beauty.
Material: low carbon steel wire, PVC coated
Manufacturing process: steel wire is coated with plastic after
welding, and can also be electroplated, hot-dip plated and coated
separately.
PVC coated welded wire mesh uses: industrial, agricultural,
municipal, transportation and other industries fence, decoration,
protection and other facilities.
PVC plastic coated electric welding network features: good
corrosion resistance, weatherability, anti-aging, beautiful and
generous. The installation is simple and fast.
Product 2: Protective Fence
Common product specifications:
(1) 5 mm - 8 mm;
(2) . mesh: 60mm x 120mm, double side wire around;
(3) . maximum size: 2300mm x 3000mm;
(4) . column: 48 mm x 2 mm steel pipe dipped in plastic treatment;
(5) . accessories: rainproof cap connecting card anti-theft bolt;
(6) . connection mode: clamping.
Product advantages
1. The grid structure is concise, beautiful and practical;
2. It is convenient for transportation and installation, and is not
limited by topography;
3. It has strong adaptability especially for mountainous area,
sloping land and bend zone;
4. The price is moderate and low, suitable for large area.
Main market: railway, highway closed network, field fence,
community fence, all kinds of isolation network.
The welded wire mesh can be made into mesh sheet. The mesh sheet
surface can be dipped or sprayed with plastic. A protective film is
formed on the convenient surface of the welded wire mesh, which can
effectively isolate the metal wire from the external water or
corrosive substances, increase the service time, and make the mesh
sheet surface present different colors, Make the mesh to achieve
beautiful effect. The plastic mesh is usually used outdoors to link
with the column, which can play the role of anti-theft.
Detailed specifications
Standard net, 30 m roll, width 0.5 m - 1.8 m |
| Mesh | Wire diameter (BWG) |
| inch | millimeter |
| 1/4" x 1/4" | 6.4 x 6.4 | 22,23,24 |
| 3/8" x 3/8" | 10.6 x 10.6 | 19,20,21,22 |
| 1/2" x 1/2" | 12.7 x 12.7 | 16,17,18,19,20,21,22,23 |
| 5/8" x 5/8" | 16 x 16 | 18,19,20,21, |
| 3/4" x 3/4" | 19.1 x 19.1 | 16,17,18,19,20,21 |
| 1" x 1/2" | 25.4 x 12.7 | 16,17,18,19,20,21 |
| 1-1/2" x 1-1/2" | 38 x 38 | 14,15,16,17,18,19 |
| 1" x 2" | 25.4 x 50.8 | 14,15,16 |
| 2" x 2" | 50.8 x 50.8 | 12,13,14,15,16 |
(PVC layer welded wire mesh), 30m roll, width 0.5m-1.2m |
| Mesh | Wire diameter (BWG) |
| inch | millimeter |
| 1/2" x 1/2" | 12.7 x 12.7 | 16,17,18,19,20,21 |
| 3/4" x 3/4" | 19 x 19 | 16,17,18,19,20,21 |
| 1" x 1" | 25.4 x 25.4 | 15,16,17,18,19,20 |
(welding fence net), 30 m roll, width 0.5m-1.8m |
| Mesh | Wire diameter (BWG) |
| inch | millimeter |
| 2"x3" | 50 x 75 | 2.0mm,2.5mm,1.65mm |
| 3"x3" | 75 x 756 | 2.67mm,2.41mm,2.11mm,1.83mm,1.65mm |
| 2"x4" | 50 x 100 | 2.11mm,2.5mm |
| 4"x4" | 100 x 100 | 2.0mm,2.5mm |
Specifications
Wire diameter(mm) | Warp spacing (mm) | Weft spacing(mm) | Net length (m) | Net width (m) |
| 10 | 100-500 | 30-300 | 1-8 | 0.5-3 |
| 9 | 100-500 | 30-300 | 1-8 | 0.5-3 |
| 8 | 100-500 | 30-300 | 1-8 | 0.5-3 |
| 7 | 50-200 | 20-300 | 1-8 | 0.5-3 |
| 6 | 50-200 | 20-200 | 1-8 | 0.5-3 |
| 5 | 50-200 | 10-200 | 1-8 | 0.5-3 |
| 4 | 30-200 | 10-200 | 1-8 | 0.5-3 |
| 2-4 | 25-100 | 10-100 | 1-6 | 0.5-3 |
| 1 | 33 | 15-80 | 2.2 | 28 |
Company Introduction
Anping longkuo wire mesh products Co., Ltd. is located in Anping
County, Hebei Province, which is the world's largest wire mesh
production base and has the reputation of "hometown of wire mesh"
in China. Our company specializes in producing all kinds of
stainless steel wire, stainless steel mesh and other series
products, with professional and technical personnel and senior
engineers, advanced production technology and strong R & D force.
