High Strength Stainless Steel Wire 316 Sample Provide Welded Wire
Mesh
Basis Information
Welded wire mesh is made of high-quality low-carbon steel wire, and
then cold plating (electroplating), hot plating, PVC plastic
coating and other surface passivation, plasticization treatment.
The results show that the mesh surface is smooth, mesh is uniform,
solder joint is firm, local machining performance is good, stable,
weather resistance and corrosion resistance are good.
Stainless steel welded wire mesh is made of high-quality stainless
steel wire. It is more acid resistant, alkali resistant, firmly
welded, beautiful and widely used.
Selling points
Welding is firm, mesh is even, mesh surface is flat, corrosion
resistance, high strength, strong protection ability, beautiful,
durable, convenient transportation and installation, high load
intensity.
Usage
Welded wire mesh is widely used in industry, agriculture,
construction, transportation, mining and other industries. Such as
machine protective cover, animal fence, flower fence, window fence,
passage fence, poultry cage, egg basket, food basket for home
office, paper basket and decoration. It is mainly used for external
walls of general buildings, pouring concrete, high-rise residential
buildings, etc., and plays an important structural role in the
thermal insulation system. During the construction, the hot-dip
galvanized and welded polystyrene grid plate is placed on the inner
side of the external wall formwork to be poured, the external
thermal insulation plate and the wall survive at one time, and the
thermal insulation plate and the wall are integrated after the
formwork is removed.
1. Application of external wall thermal insulation engineering
Galvanized welded wire mesh plays a certain role in building
thermal insulation and anti cracking engineering. There are two
kinds of plastering mesh for external wall: one is hot-dip
galvanized welded wire mesh (long service life and strong
anti-corrosion performance); The other is to change the wire
drawing welded wire mesh (economic benefits, flat mesh surface,
white and glossy), according to the requirements of the region and
the construction unit to carry out reasonable material selection,
painting construction welded wire mesh specifications are: 12.7 ×
It is 12.7mm, 19.05x19.05mm, 25.4x25.4mm, and the wire diameter is
between 0.4-0.9mm.
2. Steel structure application
The general specification of galvanized welded wire mesh for steel
structure specialty is: mesh 50 * 50 mm (2 inches), wire diameter
about 1 mm, width mostly 1.2, 1.5 m, which is customized according
to the needs of the project, and can play the role of glass wool
protection and heat preservation.
3. New mink cage
The mesh holes of the new mink cage are mostly 1 inch, and the wire
diameter is about 2 mm. The management is simple, the surface of
the cage is smooth, and the mink will not be scratched. The zinc
content of the galvanized welding net is uniform, and it is not
easy to rust. The new mink cage is more convenient to use, and the
mink's living environment is more comfortable. The price is much
cheaper than the previous mink cage of the same size, but the
overall performance is not affected at all, but better.
Detailed parameters
Mesh (inch) | Mesh (mm) | Wire diameter (BWG) |
| 1/4" x 1/4" | 6.4 x 6.4 | 22,23,24 |
| 3/8" x 3/8" | 10.6 x 10.6 | 19,20,21,22 |
| 1/2" x 1/2" | 12.7 x 12.7 | 16,17,18,19,20,21,22,23 |
| 5/8" x 5/8" | 16 x 16 | 18,19,20,21, |
| 3/4" x 3/4" | 19.1 x 19.1 | 16,17,18,19,20,21 |
| 1" x 1/2" | 25.4 x 12.7 | 16,17,18,19,20,21 |
| 1-1/2" x 1-1/2" | 38 x 38 | 14,15,16,17,18,19 |
| 1" x 2" | 25.4 x 50.8 | 14,15,16 |
| 2" x 2" | 50.8 x 50.8 | 12,13,14,15,16 |
Service
Our company can produce and process and order according to customer
requirements, and have a large number of stock in stock in regular
specifications all year round.
