Rolling Before Weaving Length 30m / roll or Requirement Galvanized
Black Steel Crimped Wire Mesh
Basis Information
Crimped Wire Mesh is a square mesh which is made of different
materials and specifications of wire by ginning machine and new
weaving machine. It has a variety of purposes.
Weight formula
2.54 / (silk warp + hole warp) = Silk warp * silk warp * mesh *
width * length / 2 + 2% ~ 5% ~ 9% bending = kg
Knitting method
Crimped Wire Mesh adopts the weaving method of pressing and bending
before forming, including bidirectional wave separation bending,
flat top bending, bidirectional bending, locking bending, rolling
before knitting
Product category
According to different materials, it can also be called wire
netting, galvanized netting, white steel netting, black steel
netting, stainless steel netting, wire rod netting and copper-clad
steel netting. According to different uses, the ginning net can
also be mine screen ginning net, pig ginning net, barbecue ginning
net, granary ginning net and decorative ginning net. According to
the shape, it can also be called knot ginning net, wrapping ginning
net and ginning net piece.
Packaging
Plastic bag, Moisture proof paper and Wooden pallet, or according
to customer requirements.
Characteristics
Beautiful structure, strong and durable. There is no unified table
for the specifications of ginning net. Many kinds of ginning net
have evolved due to the differences of wire diameter, aperture,
material and size.
There is no unified table for the specifications of ginning net.
There are many kinds of ginning net due to different materials,
wire diameter and aperture.
Usage
Widely used in mining, petroleum, chemical, construction,
mechanical accessories, protection
Net, packing net, barbecue net, barbecue net, sintering net,
hardware net, handicraft net, vibrating screen net, basket net,
food machinery net, cooker net, wall net, grain net, highway net,
railway net and infrastructure net.
In addition, it is used for the safety protection of stadium, green
fence, river, building, breeding and residence.
Specifications
Bwg
| Wire diameter
| Mesh
| Aperture
| Weight
|
| 6 | 4.8 | 1 | 20.6 | 11.5 |
| 8 | 4.05 | 2 | 9 | 16.5 |
| 10 | 3.2 | 2 | 10 | 10.5 |
| 12 | 2.6 | 3 | 5.9 | 10.5 |
| 14 | 2.0 | 3 | 6.5 | 6 |
| 14 | 2.0 | 5.08 | 0.3 | 12 |
| 14 | 2.0 | 2.1 | 1 | 2.5 |
| 14 | 2.0 | 3.6 | 1.5 | 1.9 |
| 16 | 1.6 | 4 | 5 | 5.5 |
| 17 | 1.4 | 5 | 5.1 | 5.0 |
| 18 | 1.2 | 5 | 4 | 3.6 |
| 19 | 1 | 2.3 | 0.18 | 1.45 |
| 19 | 1.0 | 6 | 3.2 | 3.0 |
| 21 | 0.8 | 7 | 2.8 | 2.3 |
| 22 | 0.7 | 8 | 2.5 | 2 |
| 23 | 0.61 | 18 | 0.8 | 3.4 |
| 24 | 0.55 | 16 | 0.1 | 2.5 |
| 24 | 0.55 | 14 | 0.12 | 4 |
